DIGITAL SATELLITE RECEIVER
3. Parental Lock
This “Parental Lock” feature sets viewing restrictions and
prevents unauthorized access to your STB through the PIN
(Personal Identification Number), which is a 4 digit number.
(The factory preset PIN Code : 0000)
On selecting this menu, you will have two options:
to set lock for any desired channel and to change your
PIN value.
Enter PIN Code.
If you have not entered your own PIN Code then the
PIN Code 0000 applies, which was set at the factory.
3.1 Set Channel Lock
Select the channel by pressing
/
, PG+/PG-,
/
or
numeric keys.
When you press the TV/RADIO key, TV list and Radio list
are toggled.
Select the channel lock by pressing RED( i ) key.
Press RED( i ) key again in order to cancel the lock.
Press OK key for confirmation.
This will lock the channel. Whenever you need to view
the channel, you will have to enter the PIN at the request
window.
After entering PIN Code to able to access a parental locked
channel, it will work on all parental locked channels.
It means that you can access all parental locked
channels with entering PIN Code on any parental locked
channel successfully.
NNoottee
: To lock the channels again, return to power on mode
after plugging off or entering the standby mode.
OPERATING THE RECEIVER
2.7 Move & Edit Channel
Select the TV/RADIO list with
/
or TV/RADIO key.
Select a channel in the TV or Radio list with
/
or
PG+/PG- keys or numeric keys.
Select channel by pressing the RED( i ) key.
Press the
/
or PG+/PG- keys to change the position of
the channel you want, and press the OK key for confirmation.
If you want to return the channel to the initial position,
do not press the OK key but press the BLUE(AUDIO) key.
To edit Channel Name
Select the TV/RADIO list with
/
or TV/RADIO key.
Select a channel to rename with
/
or PG+/PG- keys or
numeric keys.
Press GREEN(TEXT) key. Font Table will be displayed.
Select desired font table using the Num.1~6 keys.
Select desired character with
/
/
/
and then press
the OK key to paste character to the string.
NNoottee
: RED key : Backspace.
EXIT key : To exit font table without changing channel name.
PG+/PG- key : To move the highlight “Move & Edit Channel”
is applied on the all channel list.
Press the MENU key and then press the OK key
to save the set data.
OPERATING THE RECEIVER
