GB-31
GB
GB-30
DIGITAL SATELLITE RECEIVER
5. Common Interface (DSB-B350W)
This STB is equipped with two PCMCIA slots, which enable
the use of two CI-CAMS.
When a Common Interface CAM is inserted inside the PCMCIA
slot, the system detects the type of the CAM automatically and
display in the main menu.
On choosing this menu, you will be able to access the different
options available with the type of the CAM like authorizations,
pre-booking, package details etc.,
NNoottee
: The menu differs according to each inserted CAM.
If the module has not been installed yet, the phase
“Not Installed” will be accordingly indicated.
During inserting any CAM, you may have distorted video or audio.
It doesn’t mean STB is wrong.
6. Embedded Viaccess
1. Change Smart Card PIN code:
Change the PIN code of the Smartcard,
if necessary.
2. Change Parental Rating:
Change the setting for the family filter,
if necessary.
NNoottee
: This service is not offered by all channels.
3. Change Lock indicator:
You can change the lock status of the
Viaccess Smartcard.
4. Issuer Information:
Here you can call up all information stored on
the Smartcard by the publisher.
5. Authorization:
This option would indicate the authorization status
of the Smartcard.
OPERATING THE RECEIVER
4.6 Software Upgrade
You can download and upgrade the software of this STB
through ASTRA and Hotbird or Sirius satellite when the new
software is released.
NNoottee
: These satellites for upgrading software on Samsung
Brand can be changed in the future.
During downloading don’t turn off the STB.
If there is a new version of software to download, you are
asked if you will update or not.
If you press OK key, the update starts right away.
In case update is impossible, you get this message “You can’t update software!”
Or in case you don’t need to update, “You don’t need to update software!” will be displayed.
If you get information that a Transponder is changed to different one for Samsung software,
you should select ‘User Advanced Mode’ at Menu mode by using the
/
key.
Then you should set exact parameters for the new transponder for Samsung.
4.7 Receive Channel Data
If you want to receive the channel data from installed receiver,
please follow the instruction below.
Please make your own channel data, such as favorite & lock
channel with master box (installed box). Then take the master box
when you install the slave box (installing box).
1. Plug on both master & slave receivers.
2. Both receivers must be on power on mode.
3. Connect two receivers with the RS232 serial cable.
(Both end should have male connector with crossed signals)
4. Select the ‘Receive Channel Data’ and press OK key with slave receiver.
Then press OK key once more to confirm receiving channel data.
5. Select the ‘Send Channel Data’ and press OK key with master receiver.
Then press OK key once more to confirm sending channel data.
6. After receiving channel data, disconnect the RS232 serial cable.
7. Plug off and plug on to reboot the slave receiver.
NNoottee
: Use this function after removing SMART CARD or CAM modules (for model DSB-B350W).
The sequence of 4th and 5th instruction can be changed each other.
4.8 Send Channel Data
Please refer to '4.7 Receive Channel Data' above.
OPERATING THE RECEIVER
MF68-00368A_GB 10/6/05 10:37 AM Page 30
