ENGLISH INSTRUCTION FOR USE
3
INTRODUCTION
NOTE:
The numbers in brackets refer to the components shown in
Machine Description chapter.
Before operating the machine, carefully read this
manual.
SPARE PARTS AND MAINTENANCE
Any repair must be performed at an authorized Nilfisk Service Centre
by qualified personnel, using Nilfisk original spare parts and
accessories only. For more information, please contact the local dealer.
UNPACKING/DELIVERY
Upon delivery, check that the packing and the machine are not
damaged during transportation. In case of visible damages, keep the
whole packing to have it checked. Contact the Dealer immediately to
file a freight damage claim.
Check contents of package to ensure that following items are included:
1, Machine
2, Side broom (x1 or x2)
3, Side broom screws (x3 or x6)
4, Handlebar
5, Handlebar nuts(x2)
6, Instruction for use and Part list
GENERAL INSTRUCTIONS
Specific warnings and cautions about potential damage to people and
the machine are shown below.
WARNING!
To reduce the risk of fire or personal injuries:
The sweeper is not suitable for collecting dangerous powders.
The sweeper is not suitable to collect liquids.
The sweeper must be used in dry conditions, it must not be used
or kept outdoors in wet conditions.
Do not collect toxic, carcinogen, combustible materials or other
dangerous materials such as asbestos, arsenic, barium, beryllium,
lead, pesticide or other harmful materials.
Do not collect burning cigarette butts or other burning objects
such as ash, matches or similar.
To remove glass, metals or sharp objects from the hopper, wear
thick gloves to prevent personal injuries.
Empty the hopper after each use.
Do not use the sweeper on inclined surfaces.
Do not allow to be used as a toy. Pay careful attention when using
the machine near children.
Use only original Nilfisk brooms.
During the sweeper operation, foreign materials may get into the
eyes of the operator. Thus, it is advisable to wear protective
glasses.
Please be watchful. Pay careful attention to the machine
operation and use common sense. Do not use the machine when
tired, absent-minded, under the effect of drugs, alcohol or
medicines which can compromise the control over the machine.
MACHINE DESCRIPTION
(see figure on page2)
1. Handlebar Assembly as page2 B
2. Handle adjusting knobs
3. Hopper
4. Hopper handle
5. Side broom height adjusting knob
6. Side broom Assembly as page2 A
7. Main broom height adjusting knob
8. Main broom
9. Main broom adjusting indicator
10. Drive wheel
11. Caster
12. Chassis
13. Filter
14. Belt
15. Belt tension structure
16. Main broom rotation direction
17. Side broom rotation direction
SWEEPER OPERATION
1. If necessary, adjust the handlebar (1) to one of the 3
positions (show as page2 C) by using the knobs (2).
2. Hold the handlebar and push the machine forward no faster
than a normal walking pace. The machine does not work if
dragged backwards.
3. The hopper (3) should be emptied after each working cycle
and whenever it is full.
AFTER USING THE MACHINE
After working, before leaving the machine: empty the hopper (3)
and check the main broom (8) to remove foreign materials (lace,
wire, strings or similar) which can compromise the correct
operation.
To store the machine in a narrow place, fold the handlebar (1).
Loosen the knobs (2) and pull the handlebar upwards.
Fold down the handlebar and lock it.
Then place the machine in a vertical position to preserve the
broom bristles.
ADJUSTMENT
Adjust the broom height when the bristles are worn or when their
efficiency is compromised.
1. Adjust the height of the main broom (8) with the knob (7),
the yellow indicator (9) on the knob will rotate to indicate
the adjustment.
Note: If the main broom ground pressure
is adjusted over “+”, higher physical force
is required to push the machine, and the
broom wear is increased.
2. Adjust the height of the side broom (6) with the knob (5).
To turn the side broom up from the ground, screw the upper
part of the knob counter-clockwise, then fix the under part
of the knob.
In opposite, to turn the side broom down, unscrew the under
part of the knob first and then turn the upper part of the
knob clockwise, after that, fix the under part of the knob.
3. If the belt (14) is loose, adjust it by the belt tension structure
(15). Unscrew the two screws on the structure, and then
move the structure (15) to appropriate position and fix the
two screws.
After the adjustment, push the machine to check if it moves
smoothly, without difficulty or resistance. Otherwise, repeat the
adjustment procedure.
If the brooms or belt is worn, replace it.
SCRAPPING
Have the machine scrapped by a qualified scrapper.
