4.4 Digital inputs/outputs
The DSV 5445 LIFT are provided with programmable and hard-wired inputs and outputs. They are preset for
their lift application. A voltage of 30 V DC must on no account be exceeded at the inputs and outputs. The
control voltage must be smoothed using electrolytic capacitors (a transformer only with rectifier is not
sufficient!). Each output can switch a maximum current of 0.1 A at a maximum voltage of 24 V DC. The
power supply for the outputs is provided from an external source via pin 11 and pin 12 in connector X1. The
power supply is to be provided with a 2AT fuse. The inputs switch at a voltage of 15 - 24 V DC. They each
require a current of 10 mA. The voltage refers to the earth connection pin 11 in connector X1.
Digital inputs
connector X1
Pin Function Remarks
ISP 5 24 V Pulse lock-out Positive release of motor
contactor (contactor monitor)
Input 8 6 24 V Rotation direction selection Using DCP: master-direction
INT 8
Reference signal Wired to output A5 (if signal
comes not separate from plc)
0 V 11 24 V 0 V external From external power-supply
24V 12
24 V external fuse 2 AT From external power-supply
Digital outputs
connector X1
Pin Function Remarks
Output 9 2 24 V Release brake Max. load 0.1A (all outputs)
BB 3 24 V Ready for operation ‘BB’ set to high, if no fault
Digital inputs
connector X2
Pin Function (0E50=0 standard) Function (0E50=255/-256/15)
Input 0 16 24 V Enable controller Binary: Up
Input 1 15 24 V Emergency-evacuation V4 Binary: Down
Input 2 14 24 V Vi Inspection run Binary: Bin 0
Input 3 13 24 V V3 Fast gear step Binary: Bin 1
Input 4 12 24 V V2 Medium gear step Binary: Bin 2
Input 5 11 24 V V1 Small gear step Binary: Bin 3
Input 6 10 24 V Ve Approaching gear step Binary: Bin 4
Input 7 9 24 V Vn Readjustment Input not used at the moment
Digital outputs
connector X2
Pin Function Remarks
Output 0 8 24 V Controller running Motor is under current
Output 1 7 24 V V < threshold in E12 Deceleration check
Output 2 6 24 V V < threshold in E14 Door zone
Output 3 5 24 V V < threshold in E16 Over speed
Output 4 4 24 V Over temperature Motor or unit to hot
Output 5 3 24 V Parallel to X1 Pin 8 A5 to INT
Output 6 2 24 V Maximum torque reached Signal permitted only for short
period
Output 7 1 24 V Standstill End of run
PTC thermistor
input
Connector "23-24"
Pin
Function Remarks
Motor thermistor 23 Motor temperature monitoring Without motor thermistor
Motor thermistor 24 (last run is still to be ended) Please bridge "23-24“
Note: Flag 0E50 = 0 -> normal function of 7TZ-based programs, 0E50 not 0 -> binary coded input-signals !
