EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 33
7 Lift programs, firmware
7.1 Firmware TUDY..., TUDX… (asyn. gearbox-lift) and TUDZ... (syn. gearless-lift)
The lift software (i.e. the 'command programs *.KOM') in the DSV 5444/5445-Lift equipment depends upon
the firmware and the version of control-board that is being employed ('40 MHz'-TUDY or '50 MHz'-TUDX or
'50 MHz'-TUDZ). All standard winches with asynchronous motors and gearboxes normally use the version
TUDYxxN or TUDXxxN, all gearless drives and synchronous motors use the '50 MHz' version TUDZxxN …
7.1.1 Application and function of the firmware
Firmware Application Function
AUDYxxN
(40MHz)
EPROM’s have been used up to 2002-05-31 for the '40 MHz'-device and support all
normal gear winches with asynchronous motors.
TUDYxxN
40MHz
EPROM’s are in use since 2002-06-01 for the '40 MHz'-device and support all normal
gear winches with asynchronous motors.
The difference to 'AUDYxxN' is the evaluation of the output 'A0'. With command
programs from (EmoSoftLift the new parameter 'F29' determines, if the output 'A0' will
have either the known function 'control on' (F29=242) or the output 'A0' controls the
motor contactors (F29=3862). With this new function the regard of the contactors over
travel time of the control is unnecessary, because 'A0' is switching the drive contactors
always current less on or off.
TUDXxxN
50MHz
EPROM’s from 2009 witha 50-MHz-board – but for applications with gearbox-winsches
– have the same settings like units with 40-MHz-boards. The reason for changing is the
higher needed calculation-power using for example the ’DCP_04-lift-bus-sytsem’ here.
AUDZxxN
50MHz
EPROM’s have been used up to 2002-05-31 for the '50 MHz'-device and support all
gearless winches with synchronous and asynchronous motors and synchronous
motors with epicyclic gear as well.
TUDZxxN
50MHz
EPROM’s are in use since 2002-06-01 for the '50 MHz'-device and support all gearless
winches with synchronous and asynchronous motors and synchronous motors with
epicyclical gear as well.
The difference to 'AUDZxxN' is the evaluation of the output 'A0'. With command
programs from EmoSoftLift the new parameter 'F29' determines, if the output 'A0' will
have either the known function 'control on' (F29=242) or the output 'A0' controls the
motor contactors (F29=3862). With this new function the regard of the contactors over
travel time of the control is unnecessary, because 'A0' is switching the drive contactors
always current less on or off.
7.1.2 Firmware TUDY..., TUDX..., TUDZ..., AU..., with command program (*.KOM)
The software was formerly based on the connection variants '3SZ', '7SZ', '9SZ', '10SZ', and special
customised variants. After June 2002, new features are provided only in the '7TZ' based programs
(e.g. the switchover facility for output 'A0', or also in the ’10SZ’-based bus-versions.
