EMOTRON DSV 5445/5444
21.04.09 Emotron
Page 43
Adr. Variable in FU-Control Remarks TUDY/X TUDZ
E60 Service flag
V Emergency operation without encoder (set F0 at least
to 1200).
If 0E60 = '255' and jumper 'JP3' is in the middle
position (i.e. encoder not present), then the system
runs also without encoder.
Attention: The motor current can become very
large at low speeds, so that the machine catches
fire! A motor temperature monitor must always be
active; this function is not possible or permitted
with synchronous motors (accident risk).
0 0
E62 Emergencyflag
V Can be set with 7TZ, 7SZ, 10SZ, 3SZ , 9SZ versions.
”0” means here that emergency evacuation is active.
7TZ, 7SZ versions also automatically enable the
emergency evacuation by means of a 'high' signal at
'E1' (only in decimal-coded-inputmode, not so binary).
The status of flag 0E62 is thus irrelevant. The value
“0” disables the phase monitoring.
The hardware must be prepared for emergency
evacuation (terminals 24/25 must be present).
255 255
E64 DCP=92/172 ACP=87
CAN=165
V Code for selection of ACP/DCP depend from lift-plc:
Böhnke: DCP_01 = 90, DCP_03 = 92, DCP_04 = 93
Kollmorg: DCP_03 = 172, DCP_04 = 173
Newlift: ACP_01 = 85, ACP_03 = 87
92 92
E66 Baudrate DCP=2 ACP=6
V Baudrate for DCP, ACP or other bus-system:
DCP_01 = 1, DCP_03 = 2, DCP_04 = 2
ACP_01 = 6, ACP_03 = 6
2 2
E68 SG18-LG18-flag
V 7tz-based programs using TUDY/TUDX-firmware:
When 0, all status infos are stored in the fault
memory, when 255, only the error messages. Newer
gearless-files for TUDZ don’t use this value in 0E68.
Note: Using DCP_04 this value in variable 0E68
will be used for dead-time of absolute-encoder-
signal! The value-range is 50 to 250 (typ. is ’60’) !
255 255
E6A read only Resolver_V
V Resolver voltage value 85 = 6.3 V (min. 70 to max. 90
are in this case correct for the EPM series from
Alpha-Wittenstein)
85 85
E6C read only decel.-dist.
V Braking distance for direct approach after gear-down
point in mm; this parameter can only be read (value
serves to entry of the gear-down distance in the
controller and is determined only when variable 0E1A
is set to 255). When 0E1A is set to 0, the value from
parameter F26 appears here (levelling distance)!
2500
(read-only)
2500
(read-
only)
E6E read only RHO-0
V Angular displacement of the synchronous motor
(normally set to 0).
This value may not be readjusted arbitrarily.
Please pay attention to Chapters 10.2, 10.3 et seqq.
0 0
Important: The parameter 't' for asynchronous gearless-motors under 'TUDZxxN' is twice as high
as shown in the commissioning table. For synchronous gearless-motors ‘t' is constant and F0
specifies the type of motor; because of this you must not change F0 randomly. Don’t change t / F0.
