High Performance Vector Control/Torque Control Inverter User Manual
80 Chapter 6 Parameter Description
Relevant term explanation:
Terminal Xi: Refers to any of terminal X1, X2, X3, X4, X5, X6 or X7, also called terminal X.
Terminal Yi: Refers to terminal Y1, Y2 or relay also called terminal Y.
Terminal function enabled: Means that terminal Xi has set the function under description. And P7.25
adopts the leave-factory value, the terminal is closed; when the P7.25 adopts the non-leave-factory value,
the terminal is open.
The leave-factory setting of terminal Xi (i=1~7) is no function (function code set as 99).
Multi-functional input terminal definition table:
SN
Function definition SN
Function definition
0 Jog forward 27 Shutdown via terminal with DC braking 2
1 Jog reverse 28 Counter trigger input
2 Forward (FWD) 29 Counter trigger reset
3 Reverse (REV) 30~46
Reserved
4 Three-wire operation control 47
PG feedback closed loop control single
phase pulse input
5
Pulse frequency DI input (only available for
X7/DI terminal)
48 Command switching to operation panel
6 Multi-section digital voltage terminal 1 49 Command switching to terminal
7 Multi-section digital voltage terminal 2 50 Command switching to host computer
8 Multi-section digital voltage terminal 3 51
Main frequency source close loop and open
loop switching input
9 Multi-section frequency terminal 1 52 Main frequency source switching to digital
10 Multi-section frequency terminal 2 53 Reserved
11 Multi-section frequency terminal 3 54 Main frequency source switching to AI1
12 Multi-section frequency terminal 4 55 Main frequency source switching to AI2
13 Acceleration/deceleration terminal 1 56 Main frequency source switching to AI3
14 Acceleration/deceleration terminal 2 57 Main frequency source switching to DI
15 Digital regulating frequency reset 58
Auxiliary frequency source switching to
Disabled
16 Frequency increase instruction 59 Reserved
17 Frequency decrease instruction 60 Auxiliary frequency source switching to AI1
18
Acceleration/deceleration Disable
instruction
61 Auxiliary frequency source switching to AI2
19 External failure input 62 Auxiliary frequency source switching to AI3
20 Terminal failure reset input 63 Auxiliary frequency source switching to DI
21 External interrupt contact input 64 Speed control/torque control switching
22 Inverter running disabled 65 Speed limiting forced to be Pd.06 and Pd.07
23 Shutdown via terminal 66 Zero servo enable terminal
24 Free shutdown via terminal 67 Closed loop output forced to be 0
25 Shutdown via terminal with DC braking 1 68 PID positive or negative function
26 Emergency shutdown 1 (fastest shutdown)
69~98
Reserved
0: Terminal jog forward input
1: Terminal jog reverse input
2: Terminal forward run input (FWD)
3: Terminal reverse run input (REV)
The functions of above items 0 to 3 are only enabled in the terminal running command reference mode
