High Performance Vector Control Inverter/Torque Control User Manual
10 Chapter 1 Introduction toV8/V9 Series Inverter
1.9 Braking Resistor Lectotype
Braking resistor unit
Inverter model Braking unit
Braking resistor Qty.
Braking torque%
G-20P4 70W 200Ω
1 220
G-20P7 70W 200Ω
1 125
G-21P5 260W 100Ω
1 125
G-22P2 260W 70Ω
1 120
G-40P7/P-41P5 70W 750Ω
1 130
G-41P5/P-42P2 260W 400Ω
1 125
G-42P2/P-3P7 260W 250Ω
1 135
G-43P7/P-45P5 390W 150Ω
1 135
G-45P5/P-47P5 520W 100Ω
1 135
G-47P5/P-4011 780W 75Ω
1 130
G-4011/P-4015 1040W 50Ω
1 135
G-4015/P-4018
B ui l t - i n
a s
s t a n d a r d
1560W 40Ω
1 125
G-4018/P-4022 4800W 32Ω
1 125
G-4022/P-4030 4800W 27.2Ω
1 125
G-4030/P-4037 6000W 20Ω
1 125
G-4037/P-4045 9600W 16Ω
1 125
G-4045/P-4055 9600W 13.6Ω
1 125
G-4055/P-4075 6000W 20Ω
2 135
G-4075/P-4090
B u i l t - i n
a s o p t i o n
9600W 13.6Ω
2 145
Note: The connection mode for multiple braking resistors is parallel connection. For example, the inverter
of G-4055/P-4075, the braking resistor lectotype: it is suggest to select two 6000W 20Ωbraking resistor
parallel connection, amount to braking resistor is 12000W, 10Ω.
