High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 123
6.18 User-defined Function Code Displayed/hidden Zone Parameters (Group
A0)
Customize function code menu by function code of group A0. Protect the customized menu with
password A0.00.Only function code groups with corresponding Bit set as 1 by A0.01 or A0.02 can be
shown.
Note:
Factory default for password of displayed/hidden zone of user-defined function code is 1.
LSB (the least significant bit) to MSB (the most significant bit) of A0.01 correspond to P0, P1, P2,
P3, P4, P5, P6, P7, P8, P9, PA, Pb, PC, Pd, PE and d0 in turn.
LSB to MSB of A0.02 correspond to d1, d2 and reserved 14 bits in total.
Zones of PE, C, U0 and U1 are reserved for parameters by manufacturer.
When recovery practices of function code P0.01=4 or 5, the displayed/hidden function can be
reset back to factory default.
A0.00
Password of displayed/hidden zone of user-defined function code
0~FFFF
A0.01 Displayed/hidden function 1 of user-defined function code
0~FFFF
A0.02 Displayed/hidden function 2 of user-defined function code
0~FFFF
