50 Chapter 5 List of Parameters
input point A2
P6.19 Curve4 input point A3 100.0
0.0 ~ 110.0
% ○ 0.0~110.0%
P6.20
Per-unit value
B23corresponding to
curve4 input point A3
100.0
0.0 ~ 110.0
% ○ 0.0~110.0%
P6.21
AI1～AI3、DI analog
channel function selection
0000
0 ~ 6666 / ×
LED ones place: AI1 function
selection
0: Open loop frequency or close
loop analog input;
1: Torque reference 1 (torque
control operation mode);
2: Torque reference 2(torque
control operation mode);
3: Reserved;
4: Reserved;
5: Motor temperature feedback
(overload protective sensor);
6: Speed limiting (torque control
operation mode);
LED tens place: AI2 function
selection, same with above
LED hundreds place: AI3 function
selection, same with above
LED thousands place: DI
function selection, same with
above
(V9:3,4 rederve)
(V8:1, 2, 3, 4, 6 rederve)
P6.22 AI1 filtering time 0.004
0.000 ~ 1.000
s × 0.000 ~ 1.000s
P6.23 AI2 filtering time 0.004
0.000 ~ 1.000
s × 0.000 ~ 1.000s
P6.24 AI3 filtering time 0.004
0.000 ~ 1.000
s × 0.000 ~ 1.000s
Group P7 Multi-function Output Parameter
P7.00
Y1 terminal output function
selection
0 0 ~ 47 / ○
P7.01
Y2/DO terminal output
function selection
1 0 ~ 71 / ○
P7.02
Relay terminal output
function selection
14
0 ~ 47 / ○
P7.03
AO1 terminal output
function selection
48
48 ~ 71 / ○
P7.04
AO2 terminal output
function selection
49
48 ~ 71 / ○
Refer to the definitions of multi
function digital outputs of P7
group, and the definitions of multi
function analog values and pulse
output in Chapter 6.
P7.05 AO1 gain 100.0
0.0 ~ 200.0
% ○ 0.0 ~ 200.0%
P7.06 AO1 bias 0.0
0.0 ~ 200.0
% ○ 0.0 ~ 200.0%
P7.07 AO2 gain 100.0
0.0 ~ 200.0
% ○ 0.0 ~ 200.0%
P7.08 AO2 bias 0.0
0.0 ~ 200.0
% ○ 0.0 ~ 200.0%
P7.09
Selection of positive and
negative gain and bias
0000
0 ~ 1111 / ○
Ones place: AO1 gain:
0: Positive;1: Negative
Tens place: AO1 bias:
0: Positive;1: Negative
Hundreds place: AO2 gain:
0: Positive;1: Negative
Thousands place: AO2 bias:
0: Positive;1: Negative
P7.10
Y2/DO maximun output
pulse frequency selection
10.0
0.1 ~ 50.0 kHz
○ 0.1 ~ 50.0kHz
P7.18
Zero current detection width
0.0
0.0 ~ 50.0 % ○ 0.0 ~ 50.0%
P7.19
Frequency arrival detection
width
2.50
0.00 ~ 300.00
Hz ○ 0.00 ~ 300.00Hz
P7.20 FDT1 level upper limit 50.00
0.00 ~ 300.00
Hz ○ 0.00 ~ 300.00Hz
P7.21 FDT1 level lower limit 49.00
0.00 ~ 300.00
Hz ○ 0.00 ~ 300.00Hz
P7.22 FDT2 level upper limit 25.00
0.00 ~ 300.00
Hz ○ 0.00 ~ 300.00Hz
P7.23 FDT2 level lower limit 24.00
0.00 ~ 300.00
Hz ○ 0.00 ~ 300.00Hz
