High Performance Vector Control/Torque Control Inverter User Manual
Chapter 4 Using Instructions of Operation Panel 33
4.4 Menu Style
The menu style is 2-level menu.
4.4.1 Format of First Level Menu
Fig. 4−2 Format of first level menu
Dividing the first level menu
Password action area Function code area
Group number
in area
Function code range
P0 group P0.00 ~ P0.16
P1 group P1.00 ~ P1.08
P2 group P2.00 ~ P2.07
P3 group P3.00 ~ P3.13
P4 group P4.00 ~ P4.36
P5 group P5.00 ~ P5.13
P6 group P6.00 ~ P6.24
P7 group P7.00 ~ P7.25
P8 group P8.00 ~ P8.10
P9 group P9.00 ~ P9.18
PA group PA.00 ~ PA.22
Pb group Pb.00 ~ Pb.23
PC group PC.00 ~ PC.06
Pd group Pd.00 ~ Pd.36
User operation area (P area)
PE group Reserved
d0 group d0.00 ~ d0.11
d1 group d1.00 ~ d1.11
Protection area of user
password P0.00
Equipment status area (d area)
d2 group d2.00 ~ d2.24
A0.00 protection area
Function code display/hidden
area defined by user (A area)
A0 group A0.00 ~ A0.02
C0.00 reserved area Reserved (C area)
Reserved
parameter
area
Reserved
U0.00 reserved area Reserved (U0 area)
Reserved
parameter
area
Reserved
U1.00 reserved area Reserved (U1 area)
Reserved
parameter
area
Reserved
Function code area Group number Separation sign Index in group
