QSW-98ХХ Series Switch Hardware Installation and Reference Guide 15
www.qtech.ru
QSW-М-98XX-48GT-POE-M
QSW-М-98XX-48XS-UH
QSW-М-98XX-4QXS24XS-UH
QSW-М-98XX-12QXS-UH
QSW-М-98XX-24SFP8GT-L
QSW-М-98XX-24GT8SFP-L
Hot Swapping
Supported
Supervisor
Module
Redundancy
Supported
Power Supply
Module
QSW-M-98XX-PWR2-AC: 90 to 180 VAC, power: 1200W;
180 to 264 VAC, power: 1600W
QSW-M-98XX-PWR-AC: 90 to 180 VAC, power: 600W:
180 to 264 VAC, power: 600W
QSW-M-98XX-PWR-AC-POE1: 90 to 176 VAC, power: 1000W;
176 to 264 VAC, power: 1600W
QSW-M-98XX-PWR2-DC: -40.5 to -75 VDC, power: 1600W
QSW-M-98XX-PWR-DC: -40.5 to -75 VDC power: 600W
HVDC Power
Supply
QSW-M-98XX-PWR2-AC: 192 to 216 VDC, power: 1200W;
216 to 290 VDC, power: 1600W
QSW-M-98XX-PWR-AC: 192 to 290 VDC, power: 600W
The power supply supports reversible HVDC.
The HVDC-supported PDU socket should be provided.
It is recommended to install a DC air switch. During power-on, turn on the DC air switch after
connecting the power cord. During power-off, turn off the DC air switch before removing the
power cord.
Power Supply
Redundancy
The power supply redundancy of the same model is supported.
Fan Module
Three Q10-FAN-R modules and one Q10-FAN-F module
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
Operating
Humidity
10% to 90% RH (non-condensing)
Altitude
Long term operation altitude: 3000m at 50℃. The temperature decreases by 1℃ as the altitude
ranging from 3000m to 4000m increases by each 200m.
Operation altitude: 4000m max
Storage altitude: 4000m max
MTBF
259,000 hours
Noise
63.5 dB at 35°C
77.4 dB at 50°C
Weight
Net weight: 78.66 kg (including chassis and fans)
Dimensions
(W x D x H)
442 mm x 801 mm x 797.3 mm (cable management brackets excluded), 18U
442 mm x 821 mm x 797.3 mm (cable management brackets included), 18U
