2.5 Precaution for Fiber Connection

Before connecting fiber cables, make sure the model of the optical transceiver and fiber type match the optical port. The

transmit port on the local device should be connected to the receive port on the peer device and vice versa.

2.6 Unpacking Requirements

Goods Checklist

Chassis Carton

Device panels are installed and operational.

Fans, screwdriver, anti-static wrist strap, yellow/green grounding wires, quick installation guide,

packing list

Module Carton

Modules, packing list, documentation

A normal delivery should contain the above mentioned items, which may differ from the actual delivery, depending

on purchase contracts. Please check your goods carefully against the packing list or purchase contract. If you have

any questions or there are any errors, please contact your distributor.

3 Product Installation

QSW-98XX series Ethernet switch must be used and fixed in the room.

Make sure you have carefully read part 2 and this part, and be sure that the requirements set forth in part 2 have

been met.

3.1 Installation Procedure

 Install the cabinet

 Mount the switch to the cabinet

 Ground the switch

 Connect the power supply

 Install modules

 Connect external port cables

 Bundle cables

 Verify the installation

3.2 Installation Verification

The QSW-98XX is complicated equipment, so you must carefully plan and arrange the installation location, networking

mode, power supply, and wiring before installation. Verify the following before installation:

 The installation location is of a good air flow.

 The installation location meets the temperature and humidity requirements of the equipment.

 The qualified power supply is available at the installation location.

 The related network cables have already been deployed at the installation location.

 The selected power supply meets the system power.

3.3 Installing the Air Filter (Optional)

Install air filters of the supervisor module, service module and switch fabric module on the QSW-98XX.

If an air filter is used for a long time, dust may block its air vent, weakening system ventilation. It is recommended

you wash the air filter every three months.
