QSW-98ХХ Series Switch Hardware Installation and Reference Guide 9
www.qtech.ru
The chassis should be mounted in a place with sufficient space for air circulation. Sufficient space (10 cm at least)
must be reserved at the air intakes and exhaust vents for ventilation.
If any module slot is unoccupied, install a filler panel to enable proper airflow.
1.2 QSW-9807
Specifications
Model
QSW-9807
Module Slot
Two supervisor module slots, five service module slots
Supervisor Module
QSW-M-98XX-MC
Switch Fabric
Module
Not supported
Service Module
QSW-М-98XX-8XS-M
QSW-М-98XX-4XS44SFP-M
QSW-М-98XX-4XS24GT20SFP-M
QSW-М-98XX-48GT-M
QSW-М-98XX-48GT-POE-M
QSW-М-98XX-48XS-UH
QSW-М-98XX-4QXS24XS-UH
QSW-М-98XX-12QXS-UH
QSW-М-98XX-24SFP8GT-L
QSW-М-98XX-24GT8SFP-L
Hot Swapping
Supported
Supervisor Module
Redundancy
Supported
Power Supply
Module
QSW-M-98XX-PWR2-AC: 90 to 180 VAC, power: 1200W;
180 to 264 VAC, power: 1600W
QSW-M-98XX-PWR-AC: 90 to 180 VAC, power: 600W:
180 to 264 VAC, power: 600W
QSW-M-98XX-PWR-AC-POE1: 90 to 176 VAC, power: 1000W;
176 to 264 VAC, power: 1600W
QSW-M-98XX-PWR2-DC: -40.5 to -75 VDC, power: 1600W
QSW-M-98XX-PWR-DC: -40.5 to -75 VDC power: 600W
HVDC Power
Supply
QSW-M-98XX-PWR2-AC: 192 to 216 VDC, power: 1200W;
216 to 290 VDC, power: 1600W
QSW-M-98XX-PWR-AC: 192 to 290 VDC, power: 600W
The power supply supports reversible HVDC.
The HVDC-supported PDU socket should be provided.
It is recommended to install a DC air switch. During power-on, turn on the DC air switch
after connecting the power cord. During power-off, turn off the DC air switch before
removing the power cord.
Power Supply
Redundancy
The power supply redundancy of the same model is supported.
Fan Module
Q07-FAN
Operating
Temperature
0°C to 50°C
Storage
Temperature
-40°C to 70°C
