The weight only includes that of the empty chassis and fans. The whole device's weight is subject to that of the

modules selected.

The QSW-9810 switch is an A-class product and may cause radio disturbance to surroundings. In this case, users

are advised to take proper measures against the disturbance.

Product Appearance

The hardware system of the QSW-9810 switch is composed of the chassis, power system, system modules and cooling

system.

 The power system provides eight power supply slots and supports N+M power supply redundancy. Users are

recommended to configure redundancy for the power supplies.

 The power system also provides two PoE power supply slots and supports 1+1 power supply redundancy. Users are

recommended to configure redundancy for the power supplies.

 The QSW-9810 provides two supervisor module slots, eight service module slots and four switch fabric module slots.

The supervisor modules support 1+1 redundancy. We recommend users to configure redundancy for supervisor

modules. Users may select different service modules as needs.

 The heat dissipation system is composed of fan trays and air filters. The system fan tray is at the back of the chassis,

the fan tray of the switch fabric module is in the front of the chassis, and the air filter is at the bottom of the front

panel.
