11
Specifi cations
17 690 01 Rev. J KohlerEngines.com
ENGINE IDENTIFICATION NUMBERS
Kohler engine identifi cation numbers (model, specifi cation and serial) should be referenced for effi cient repair,
ordering correct parts, and engine replacement.
Model . . . . . . . . . . . . . . . . . . . . . CH260
Command Engine
Horizontal Shaft
Numerical Designation
Specifi cation . . . . . . . . . . . . . . . CH260-0001
Serial . . . . . . . . . . . . . . . . . . . . . 4423500328
Year Manufactured Code Factory Code
Code Year
44 2014
45 2015
46 2016
GENERAL SPECIFICATIONS
3,6
CH260/CH270 CH395 CH440
Bore 70 mm (2.8 in.) 78 mm (3.1 in.) 89 mm (3.5 in.)
Stroke 54 mm (2.1 in.) 58 mm (2.3 in.) 69 mm (2.7 in.)
Displacement 208 cc
(12.7 cu. in.)
277 cc
(16.9 cu. in.)
429 cc
(26.2 cu. in.)
Oil Capacity (refi ll) 0.6 L
(0.63 U.S. qt.)
1.1 L
(1.16 U.S. qt.)
1.3 L
(1.37 U.S. qt.)
Maximum Angle of Operation (@ full oil level)
4
25°
TORQUE SPECIFICATIONS
3,5
CH260/CH270 CH395 CH440
Air Cleaner
Quad-Clean
™
Air Cleaner Base Mounting Screw 8.0 N·m (71 in. lb.)
Low-Profi le Air Cleaner Base Mounting Screw 6.7 N·m (59 in. lb.)
Blower Housing and Sheet Metal
M6 Screw 10 N·m (89 in. lb.)
M6 Nut 8.0 N·m (71 in. lb.)
Carburetor
Stud 10 N·m (89 in. lb.)
Primary Nut 8 N·m (71 in. lb.)
Intake Cover Nut 4 N·m (35 in. lb.)
Intake Cover Screw 1.3 N·m (12 in. lb.)
Connecting Rod
Cap Fastener (torque in increments) 12 N·m
(106 in. lb.)
20 N·m (177 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
4
Exceeding maximum angle of operation may cause engine damage from insuffi cient lubrication.
5
Lubricate threads with engine oil prior to assembly.
6
Any and all horsepower (hp) references by Kohler are Certifi ed Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certifi ed Power Ratings can be found at KohlerEngines.com.
