Kohler Command PRO CH260 [12/100] Speciﬁ cations

Speciﬁ cations

KohlerEngines.com 17 690 01 Rev. J

TORQUE SPECIFICATIONS

3,5

CH260/CH270 CH395 CH440

Crankcase

Oil Drain Plug 18 N·m (13 ft. lb.)

Closure Plate Screw 24 N·m (212 in. lb.)

Cylinder Head

Fastener (torque in 2 increments) First to 12 N·m

(106 in. lb.)

Finally to 24 N·m

(212 in. lb.)

First to 18 N·m (159 in. lb.)

Finally to 36 N·m (319 in. lb.)

Electric Starter

Mounting Screw 24 N·m (212 in. lb.)

Electric Starter Drive CH440 Type II Starter

Assembly Screw 5 mm --- --- 5.8 N·m (51 in. lb.)

Brush Lead Connector Wire Screw 4 mm --- --- 1.7 N·m (15 in. lb.)

Electric Starter Relay (Solenoid) CH395, CH440

Mounting Screw --- 3.2 N·m (28 in. lb.)

Nut --- 4.5 N·m (40 in. lb.)

Flywheel

Retaining Nut 74 N·m

(655 in. lb.)

113 N·m (1000 in. lb.)

Fuel Tank

Mounting Nut 24 N·m (212 in. lb.)

Mounting Screw 24 N·m (212 in. lb.)

Inlet Fitting 1.5 N·m (13 in. lb.)

Gear Reduction

M6 Screws 7.4 N·m (66 in. lb.)

M8 Screws 24.4 N·m (216 in. lb.)

Governor (Electronic)

Electronic Governor Control to Crankcase 24 N·m (212 in. lb.)

Governor (Mechanical)

Lever Nut 12 N·m (106 in. lb.)

Throttle Control Lever Nut 9 N·m (80 in. lb.)

Values are in Metric units. Values in parentheses are English equivalents.

Lubricate threads with engine oil prior to assembly.
