Specifi cations
16 24 690 02 Rev. MKohlerEngines.com
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
TORQUE SPECIFICATIONS
3,5
ECV630-ECV680 ECV730-ECV749 CV26 CV735 CV745
Speed Control Bracket
Fastener Assembled to
Cylinder Heads
10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Fastener Assembled to Blower
Housing
2.8 N·m (25 in. lb.) into new holes
2.3 N·m (20 in. lb.) into used holes
Fastener Torque 10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
Starter Assembly
Thru Bolt
Nippondenso (Solenoid
Shift)
Delco-Remy (Solenoid
Shift)
5.6-9.0 N·m (49-79 in. lb.)
4.5-7.5 N·m (40-84 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 16.0 N·m (142 in. lb.) 15.3 N·m (135 in. lb.)
Brush Holder Mounting Screw
Delco-Remy Starter
2.5-3.3 N·m (22-29 in. lb.)
2.5-3.3 N·m (22-29 in. lb.)
Starter Solenoid
Mounting Hardware
Nippondenso Starter
Delco-Remy Starter
4.0-6.0 N·m (35-53 in. lb.)
6.0-9.0 N·m (53-79 in. lb.)
4.0-6.0 N·m (35-53 in. lb.)
Nut, Positive (+) Brush Lead
Nippondenso Starter
Delco-Remy Starter
8.0-11.0 N·m (71-97 in. lb.)
8.0-12.0 N·m (71-106 in. lb.)
8.0-11.0 N·m (71-97 in. lb.)
Stator
Mounting Screw 6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
6.2 N·m (55 in. lb.)
Valve Cover
Fastener
Gasket Style Cover
Black O-Ring Style Cover
w/Shoulder Screws
w/Flange Screws and
Spacers
Yellow or Brown O-Ring
Style Cover w/Integral
Metal Spacers
6.2 N·m (55 in. lb.)
3.4 N·m (30 in. lb.)
5.6 N·m (50 in. lb.)
9.9 N·m (88 in. lb.)
6.2 N·m (55 in. lb.)
CLEARANCE
SPECIFICATIONS
3
ECV630-ECV680 ECV730-ECV749 CV26 CV735 CV745
Camshaft
End Play (with shim) 0.051/0.381 mm (0.002/0.015 in.) 0.076/0.127 mm (0.0030/0.0050 in.)
Running Clearance 0.025/0.105 mm (0.001/0.004 in.) 0.025/0.063 mm (0.0010/0.0025 in.)
Bore I.D.
New
Max. Wear Limit
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
Bearing Surface O.D.
New
Max. Wear Limit
19.920/19.975 mm (0.7843/0.7864 in.)
19.914 mm (0.7840 in.)
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
