Specifi cations
18 24 690 02 Rev. MKohlerEngines.com
CLEARANCE
SPECIFICATIONS
3
ECV630-ECV680 ECV730-ECV749 CV26 CV735 CV745
Crankshaft (continued)
Connecting Rod Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper Limit
Max. Out-of-Round Limit
35.950/35.973 mm (1.4153/1.4163 in.)
35.941 mm (1.4150 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
35.955/35.973 mm (1.4156/1.4163 in.)
35.94 mm (1.415 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
Crankshaft T.I.R.
PTO End, Crank in Engine
Entire Crank, in V-Blocks
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
Cylinder Bore
Bore I.D.
New
80.000/80.025 mm
(3.1496/3.2689 in.)
83.006/83.031 mm
(3.2680/3.2689 in.) 82.988/83.013 mm (3.2672/3.2682 in.)
Max. Wear Limit 80.075 mm
(3.1526 in.)
83.081 mm
(3.2709 in.)
83.051 mm (3.2697 in.)
Max. Out-of-Round 0.120 mm (0.0047 in.) 0.12 mm (0.0047 in.)
Max. Taper 0.05 mm (0.0020 in.) 0.05 mm (0.0020 in.)
Cylinder Head
Max. Out-of-Flatness 0.076 mm (0.003 in.) 0.076 mm (0.003 in.)
Governor
Governor Cross Shaft-to-
Crankcase Running Clearance
6 mm Shaft
8 mm Shaft
0.025/0.126 mm (0.0009/0.0049 in.)
0.013/0.075 mm (0.0005/0.0030 in.)
0.025/0.126 mm (0.0009/0.0049 in.)
Cross Shaft O.D.
New
Max. Wear Limit
6 mm Shaft
8 mm Shaft
7.949/8.000 mm (0.3129/0.3149 in.)
7.936 mm (0.3124 in.)
0.013/0.075 mm (0.0005/0.0030 in.)
0.025/0.126 mm (0.0009/0.0049 in.)
Governor Gear Shaft-to-
Governor Gear Running
Clearance
0.090/0.160 mm (0.0035/0.0063 in.) 0.015/0.140 mm (0.0006/0.0055 in.)
Gear Shaft O.D.
New
Max. Wear Limit
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
Ignition
Spark Plug Gap 0.76 mm (0.030 in.)
Ignition Module Air Gap 0.28/0.33 mm (0.011/0.013 in.)
Speed Sensor Air Gap 1.50 ± 0.25 mm (0.059 ± 0.010 in.)
Crankshaft Position Sensor Air
Gap (only on earlier design
sensor bracket)
0.2-0.7 mm (0.008-0.027 in.)
Crankshaft Position Sensor
Max. Air Gap (only on later
design sensor bracket)
2.794 mm (0.110 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
