Specifi cations
1724 690 02 Rev. M KohlerEngines.com
CLEARANCE
SPECIFICATIONS
3
ECV630-ECV680 ECV730-ECV749 CV26 CV735 CV745
Connecting Rod
Connecting Rod-to-Crankpin
Running Clearance @ 21°C
(70°F)
New
Max. Wear Limit
0.043/0.073 mm (0.0017/0.0029 in.)
0.088 mm (0.0035 in.)
0.030/0.055 mm (0.0012/0.0022 in.)
0.070 mm (0.0028 in.)
Connecting Rod-to-Crankpin
Side Clearance
0.26/0.63 mm (0.0102/0.0248 in.) 0.26/0.63 mm (0.0102/0.0248 in.)
Connecting Rod-to-Piston Pin
Running Clearance @ 21°C
(70°F)
0.015/0.028 mm (0.0006/0.0011 in.) 0.015/0.028 mm (0.0006/0.0011 in.)
Piston Pin End I.D. @ 21°C
(70°F)
New
Max. Wear Limit
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
Crankcase
Governor Cross Shaft Bore
I.D. (Mechanical Governor)
New
Max. Wear Limit
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
6 mm Shaft
New
Max. Wear Limit
8 mm Shaft
New
Max. Wear Limit
6.025/6.050 mm (0.2372/0.2382 in.)
6.063 mm (0.2387 in.)
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
Crankshaft
End Play (free) 0.025/0.635 mm (0.001/0.025 in.) 0.070/0.590 mm (0.0028/0.0230 in.)
Bore (in crankcase)
New
Max. Wear Limit
40.972/40.997 mm (1.6131/1.6141 in.)
41.011 mm (1.6146 in.)
40.965/41.003 mm (1.6128/1.6143 in.)
41.016 mm (1.6148 in.)
Bore (in oil pan)
New 40.974/41.000 mm (1.6131/1.6141 in.) 40.987/40.974 mm (1.6136/1.6131 in.)
Crankshaft to Sleeve Bearing
(oil pan) Running Clearance
New 0.03/0.12 mm (0.001/0.005 in.) 0.03/0.09 mm (0.0012/0.0035 in.)
Crankshaft Bore (oil pan)-to-
Crankshaft Running Clearance
New 0.039/0.087 mm (0.0015/0.0034 in.) 0.039/0.074 mm (0.0015/0.0029 in.)
Flywheel End Main Bearing
Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper Limit
Max. Out-of-Round Limit
40.913/40.935 mm (1.6107/1.6116 in.)
40.843 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Oil Pan End Main Bearing
Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.843 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
