FOR YOUR SAFETY
Use the device only for the purpose for which it is intended, observing the safety precautions provided. The user is solely
responsible for any immediate or consequential damage caused by improper use. Do not operate the device if the cable or housing
appears defective in any way. A damaged cable cannot be repaired or replaced. In this case, the device is considered inoperable and
must be disposed of. Connection to the electrical power supply is only permitted with shock-proof electrical outlets according to
DIN/VDE 0100 Parts 737, 738 and 702. Operate the device only using a residual current device (RCD) with a rated residual current not
exceeding 10/30 mA. The power supply must match the rating plate specifications. Never carry or pull the device by the cord.
In order to guarantee safety we have encapsulated all electrical parts of the pump that are not insulated in synthetic resin. For
constructive reasons there remains an empty space in the rear part of the casing where water will collect during operation. This presents
absolutely no danger and warrants no further consideration.
Use in garden ponds or pools is only permitted when done in accordance with legal provisions. Consult a qualified electrician if you have
any questions.
The device must never be operated if there are persons in the water. Switch off the current to all devices that are connected to water
before carrying out any cleaning or maintenance work on the device.
The device must not be used in chlorinated water, acidic or alkaline solutions. The device is not designed for use in salt water. Do not let
the pump run dry. This can cause irreparable damage.
Operation
The pump is driven by a magnetic impeller in a leak- proof synchronous motor.
The water must flow into the inlet port of the pump under its own pressure. The pump is not self-priming.
The flow of the pipe and the additional outlet can be adjusted by turning the regulation valves (models SP 1200 / SP2500 / SPF
3000 only).
A built-in thermal cut-off switch automatically switches the pump off if it should overheat; when the pump has cooled down
sufficiently the switch automatically turns the pump on again.
START-UP
Only start up the pump in accordance with the safety instructions. Use directly in the water to operate fountains or pond figures. The
pump should be placed horizontally in the pond below the water level.
1. Fit the adjustable pipe with the desired accessory as included in the pump kit.
2. Place the device on a flat level surface which is raised from the bottom of the pond. This will prevent the pump from clogging up too
quickly.
3. You should however make sure that the motor axle is horizontal, as otherwise the axle will be subject to increased wear.
4. Make sure that the pump is filled with water.
5. The adjustable pipe can be swivelled in order to have the right position of the spray (models SP 1200 / SP2500 / SPF 3000 only).
6. The pump will automatically start when you plug it in at an electrical outlet.
MAINTENANCE AND CARE
Remove the plug from the electrical outlet before carrying out any maintenance work.
Clean the accessory mounted on the adjustable pipe and filter sponge on the pump at regular intervals, especially when you notice a
deterioration in the performance of the pump.
Cleaning
1. Remove the adjustable pipe.
2. Press the button(s) (A) and open the top part of the housing.
3. Take the pump together with the filter sponge out of the bottom part of the housing. Remove the filter sponge (B).
4. Clean the filter sponge by washing it out thoroughly under running cold water (C). If the pump is very dirty you should also clean the
impeller.
The filter sponge used in the model SPF3000 contains activated carbon; it should be replaced when necessary or each
year at the latest.
5. Open the bayonet connector of the pump chamber lid (3) by twisting it a quarter turn. Remove the pump chamber lid. Take off the
impeller (6) (pull firmly to overcome the magnetic force) . Be careful not to lose the rubber washers (7) and not to break the ceramic
axle (5).
6. Wash the impeller out thoroughly with clean, cold water (D). Do not to use any implement to remove dirt from the inside of the
pump but simply wash it out with water. Use a soft sponge to remove any dirt deposits.
7. Reassemble the pump by following the steps in reverse order. Make sure the rubber washers (7) and the O-ring (4) are seated
correctly. Take care when working near the electrical connection of the cord to the pump.
8. Insert the plug in the electrical outlet briefly (approx. 3 sec) to ensure that the impeller (6) is running trouble-free. A certain level of
noise is inevitable during this dry run. However, this is no cause for concern. When used in water, the pump should operate silently.
Storage in Winter
We recommend placing the pump in a water-filled vessel and keeping it in a frost-free room. Storage in water prevents deposits from
accumulating on the pump. If the pump is stored dry, these deposits can block the impeller.
SPARE PARTS
Spare parts can be obtained from your dealer or direct from AL-KO. Be sure to quote the part number (see the exploded view).
Subject to technical modifications without notice.
