Ricoh Aficio BP20 [20/172] Setting up your printer

This chapter provides step by step information on setting up

your printer.

This chapter includes:

• Unpacking

• Installing the Toner Cartridge

• Loading Paper

• Connecting a Printer Cable

• Turning the Printer On

• Printing a Demo Page

• Installing Printer Software

• Reinstalling Printer Software

• Removing Printer Software

• Using the Set IP (BP20N only)

Setting Up Your Printer
