201
Printing
The custom setting is registered and added to the list.
8. Select the custom setting, and click [OK].
z
If you do not want to reduce images from documents larger than A4/Letter, clear the [Reduce automatically to fit A4] check box in the
[Printer Configuration] tab. This is useful if you want to print document images at full size even if they run off the paper.
z
p.168 "Two Types of Printer Properties Dialog Box"
z
For details about [Reduce automatically to fit A4]/[Reduce automatically to fit Letter], see the printer driver Help.
Rotating the Image by 180 Degrees
Follow the procedure below to print images rotated by 180 degrees. Use this function if paper loaded in the
paper tray has a distinct top and bottom and printing with the paper in that orientation would otherwise make
the image upside-down.
1. Open the file you want to print from the application, and then open the printer properties dialog
box.
2. Click [Add/Change Custom Settings...], and click [Page Settings] tab.
If the dialog box type is Multi-tab, click [Page Settings] tab.
3. Select the [Rotate by 180 degrees:] check box.
4. Make the necessary settings, and then click [Save...].
If the dialog box type is Multi-tab, make the necessary settings, and then click [OK].
5. In the [Custom Setting name:] box, enter a custom name.
6. Click [OK].
The custom setting is registered and added to the list.
7. Select the custom setting, and click [OK].
z
p.168 "Two Types of Printer Properties Dialog Box"
Printing on Registered Custom Size Paper
Follow the procedure below to print on registered custom size paper.
z
Register the size of the custom size paper loaded in the paper tray in the [Printer Configuration] tab.
1. Open the [Page Setup] dialog box from the application.
The [Page Setup] dialog box is usually opened by clicking [Page Setup...] on the [File] menu, but the
method to open it may differ in some applications. Open the dialog box according to the application being
used.
2. Open the printer properties dialog box from the [Page Setup] dialog box.
3. In the [Original size:] list, select a custom paper size.
Select from the sizes already registered.
