Making Printer Settings

10. The optimal adjustment value is the difference between the single vertical line and the cross's ver-

tical line that you can see when the folded paper is held up to light. When the difference is one

calibration mark in the "+" direction, the optimal adjustment value for the [Printing direction:] is

"+1.0".

11. Fold the test pattern sheet in half widthwise, and then check the adjustment value for the [Paper

feed direction:]

Adjustment values are in 0.1 increments.

12. In the [Printing direction:] and [Paper feed direction:] boxes, enter the adjustment values (-4.0 to

+4.0) from step 8

13. Click [Finish].

If a test pattern does not print or the image is not clear, select the [Print a test pattern and return to this

screen] check box, and then click [Next >]. A registration test pattern is printed and the dialog box dis-

played in step 12

p.168 "Two Types of Printer Properties Dialog Box"

Adjust Paper Feed

If horizontals are misaligned, images are patchy, or a black or white lines appear at regular intervals, print a test

pattern, and then adjust the paper feed setting.

To check the printed test pattern, proceed to step 7

1. Open the printer properties dialog box.

2. Click the [Maintenance] tab.

3. Click [Adjust Paper Feed].

4. Click [Next >].

5. Check that A4/Letter size paper is loaded in the paper tray.

6. Click [Next >].

A test pattern to adjust paper feed is printed.

Do not perform other operations during printing.
