43
Paper
8. Push tray 2 gently in until it stops.
Loading Paper into Bypass Tray (optional)
Follow the procedure below to load paper into bypass tray.
A4/Letter size paper is loaded here.
1. Pull the bypass tray extension out all the way.
2. Load paper in the bypass tray with the side to be printed on facing up.
