• Default: Off
• This menu appears only when the optional duplex unit is installed.
Blank Pages
You can specify whether or not to print blank pages.
• Print
• Do not print
• Default: Print
Output Tray
Specify the output tray that is selected by priority if the output tray is not explicitly specified.
Job Separation
This appears on the menu only when the optional finisher is installed.
Specify whether to perform shift for each job on the output tray equipped with the shift function.
• On
• Off
• Default: Off
Rotate 180 Deg.
You can select whether or not to rotate the image by 180 degrees when printing.
• On
• Off
• Default: Off
Energy Saver
You can specify the number of minutes Energy Saver mode is applied.
E.Saver On/Off
You can specify whether or not to switch Energy Saver.
• On
• Off
• Default: On
4. Making Printer Settings Using the Control Panel
146
