• When the printer switches to Energy Saver mode, the Power indicator is unlit, but the Online
indicator remains lit.
E.Saver Timer
You can select the lead time needed to switch to the Energy Saver mode. The Energy Saver
mode reduces electric power consumption.
• 1 minute
• 5 minutes
• 15 minutes
• 30 minutes
• 45 minutes
• 60 minutes
• Default: 60 minute
Auto Reset Time
Auto Reset
Specify whether to revert to the initial configuration at certain interval. This also specifies
the interval to reset the configuration.
• On
• Off
• Default : On
Reset Time (sec)
• 10 to 999 sec by 1 sec.
• Default : 60 seconds
Auto Del. Temp
This appears on the menu only when the hard disk is installed.
Specify whether to automatically delete temporarily saved documents (Sample Print, Locked
Print and Hold Print data), such as sample print documents or confidential documents. Also
specify the time period to elapse before deletion.
Auto Delete
• On
• Off
System Menu
147
