Grillo CL 75 [11/61] Instructions for use

CL75/ Translation of the original instructions

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged during transport.

2) Check the oil levels of the engine and hydrostatic transmission.

3) Check the tyre pressure: 1,5 BAR.

4) Turn the handlebar.

5) Install the front wheel support (fig.5).

6) Tighten the clamping and regulating screws of the front-wheel support firmly. The bearing inside the

BEFORE STARTING THE ENGINE

Before starting the engine, always check that:

– the engine oil level is correct (fig. 8, ref. A) – (see the appropriate manual).

– the air fins for the engine cooling system are clean (fig. 10).

– the air filter is thoroughly clean (fig. 1, no. 13) – (see the appropriate manual).

– the mowing deck is clean.

– the fins on the hydraulic motor are thoroughly clean (fig. 14).

– the blades are well sharpened and secured to the blade holder.

Fill the fuel tank with fresh fuel using a funnel. (fig. 1, no.12).

STARTING THE ENGINE

– Choose the desired cutting height using the lever (fig. 1, n°10). Suitably accelerate the engine, press

both levers (fig. 1, no. 1) and engage the PTO lever (fig. 1, n. 2 – in the picture the PTO is not engaged).

Gently operate the forward lever (fig. 1, n. 3) and start working. To stop the machine, release both levers

on the handlebar (fig. 1, n. 1). The rotation of the blade disengages automatically.

– The lever (fig. 1, no. 3) is used to select the working speed and to engage the reverse gear. Pushing

the lever forward, the mower moves forward; pulling the lever backwards, the machine moves in reverse

– remember to always pull the lever gently. When both levers on the handlebar are released (fig. 1, no.

1) the lever in reverse gear (fig. 1, no. 3) goes automatically back to the STOP position.

- a knob is located on the forward/reverse gear lever (fig. 1, no. 3) there is a knob (fig. 1, no. 9) that is

used to make the lever softer or harder. The machine is equipped with a device that automatically
