Grillo CL 75 Инструкция по эксплуатации онлайн [5/61] 520664
![Grillo CL 75 Инструкция по эксплуатации онлайн [5/61] 520664](/views2/1651323/page5/bg5.png)
Caution! Never touch moving pulleys or belts. They can be very
dangerous. Never do maintenance with engine running.
Attenzione! Non toccare mai pulegge o cinghie in movimento, creano
gravi danni alla persona. Non fare manutenzione col motore in moto.
Attention! Ne jamais toucher ni poulies ni courroies en mouvement,
elles peuvent provoquer des accidents aux personnes. Ne pas faire
l’entretien quand le moteur est en marche.
Vorsicht! Nie laufende Riemenscheiben oder Treibriemen anfassen,
da es gefährlich ist. Nie bei laufendem Motor Instandhaltung machen.
¡Atención! No tocar jamás poleas o correas en movimiento, porque
pueden crear graves daños a la persona. No efectuar el
mantenimiento con el motor en marcha.
Atenção! Nunca toque nas polias ou correias em movimento devido
ao alto risco de ferimentos. Nunca faça a manutenção da máquina
com o motor ligado.
A burst which separates the tyre from the rim parts can cause serious
injury or death.
La separazione fra pneumatico e cerchione, causata dall’esplosione
del pneumatico, può provocare serie ferite o addirittura la morte.
La séparation entre le pneu et la jante, provoquée par l’explosion
d’une roue peut causer des dommages, blessures ou la mort.
Die Trennung der Räder von den Felgen durch Explosion kann
schwere Verletzungen oder den Tod verursachen.
La separación entre el neumático y la llanta producida por la
explosión del neumático puede provocar graves herida e incluso la
muerte.
A separação entre o pneumático e o aro, provocada pela explosão do
pneumático, pode causar graves ferimentos ou até mesmo a morte.
Handle fuel with care, it is highly flammable: Do not refuel machine
while smoking, when machine is near an open flame or sparks, or
when the engine is running. Stop the engine.
Maneggiare il carburante con cura, è altamente infiammabile; non fate
rifornimento mentre fumate, o vicino a fiamme o scintille, o quando il
motore è acceso.
Manier avec soin le carburant car c’est très inflammable. Ne pas
remplir le réservoir si vous êtes en train de fumer ou pendant que la
machine est près du feu ou d’étincelles ou encore pendant que la
machine travaille. Arrêter le moteur.
Treibstoff vorsichtig handhaben, da er sehr entzündbar ist: beim
Tanken nicht rauchen. Nicht tanken, wenn die Maschine in der Nähe
von Flammen oder Funken ist oder wenn der Motor läuft. Immer den
Motor abschalten.
Manejar el combustible con cuidado porque es sumamente
inflamable; no repostar mientras se fuma o cerca de llamas o chispas,
o cuando el motor está encendido.
Manuseie o carburante com cuidado, pois este è altamente
inflamável; não fume durante o abastecimento da máquina ou
enquanto o motor estiver ligado, não o aproximado de chama ou de
faíscas.
