1 Appendix A

1.1 What Is in This Chapter

Overview This chapter covers the following topics:

Topic See page

1.2–Sound Pressure Level EWWD-CJYNN 5–4

1.3–Sound Pressure Level Correction Factor for Different Distances 5–5

1.4–Standard Ratings EWWD340-800CJYNN 5–6

1.5–Standard Ratings EWWD900-C13CJYNN 5–7

1.6–Standars Ratings EWWDC14-C19CJYNN 5–8

1.7–Evaporator Pressure Drop: EWWD-CJYNN 5–9

1.8–Condensor (1 pass) - Heat Recovery Condenser (1 pass) Pressure Drop:

EWWD-CJYNN

5–10

1.9–Partial Heat Recovery Ratings EWWD340-C19CJYNN 5–11

1.10–Heating Capacity Correction Factors for Different Evaporator Leaving Water

Temperatures

5–13

1.11–Total Heat Recovery Ratings EWWD340-C10CJYNN 5–14

1.12–Total Heat Recovery Ratings EWWDC11-C19CJYNN 5–16
