The Digital Controller ESIE07-05
2–24 Part 2 – Functional Description
3
1
2
4
5
Condenser outlet
water temperature
This screen shows the Condenser outlet water temperature (WHS in heat pump or pursuit mode)
Percent
compressor status
This screen shows the Percent compressor status
Suction and
discharge pressure
and saturated
temperature
This screen shows the Suction and discharge pressure and saturated temperature
Suction
temperature,
suction and
discharge
superheat,
expansion valve
position
This screen shows the Suction temperature, suction and discharge superheat, expansion valve
position
Water Temperatures
LVG Rec
=
xxx ˚C
Possible status :
P Off Alarm : Compressor OFF for alarm
P Off Switch : Compressor OFF by local switch
P Off Ready : Compressor OFF ready to start
P Oil Heating : Compressor waiting for oil heating
P Manual Off : Compressor disabled by keypad
P Recycle Time : Compressor waiting for timing
P Starting : Compressor starting
P Pre Purge : Compressor unloading at starting
P Auto xx% : Automatic control of compressor with percent load
P Manual xx% : Manual control of compressor with percent load
P Downl. : Compressor download before stop
P Pumping down : Compressor pump down
Comp. #1
Status:
Auto
xxx%
Evap
Evap
Cond
Cond
Press
Temp
Temp
Press
barg
˚C
barg
˚C
xx.x
xx.x
xx.x
xx.x
Suction
Suct
DelivSupHeat
Valve
Temp
SupHeat
Position
˚C
˚C
˚C
xxxx
xx.x
xx.x
xx.x
