ESIE07-05 Functional Control
Part 2 – Functional Description 2–57
3
2
4
5
1
2.6 Freeze-up Control
Introduction Freeze up control is used to protect the evaporator against accidentally freezing.
Two protections are present: freeze-up prevention and Anti-freeze alarm.
Freeze-up
prevention
Freeze-up prevention will request a load-down when the temperature of the evaporator outlet gets
below 3°C (freeze prevention setpoint).
The unit will go back to normal operation (possibility to load up) when the outlet temperature gets
above freeze prevention setpoint + diff.
Anti-freeze alarm When the evaporator outlet water temperature drops below Anti-freeze alarm setpoint (2°C) the
Anti-freeze protection is activated and the unit will shutdown. When the temperature rises above the
Anti-freeze setpoint + diff (3°C) it is possible to reset the Anti-freeze alarm.
Remark: In case of 2 evaporators, each evaporator has its own Anti-freeze alarm setpoints
Characteristics Freeze-up prevention
Control device Sensor (1 sensor at each evaporator outlet)
Diagram name
Activation Outlet water temp < Freeze prevention setpoint
(3°C)
Result Load down compressor
Reset Outlet water temp > Freeze prevention setpoint
+ diff (4°C)
Result Normal mode
Characteristics Anti-freeze alarm
Control device Sensor (1 sensor at each evaporator outlet)
Diagram name
Activation Outlet water temp < Anti-freeze setpoint (2°C
for standard unit)
Result Unit disabled
Result Manual reset
Manual reset possible when outlet temp is
above Anti-freeze setpoint + diff.
