ESIE07-05 Functional Control
Part 2 – Functional Description 2–49
3
2
4
5
1
2.3 Thermostat Control
Introduction The thermostat control is used to generate a load-up or load-down according to the active PID
regulation.
Continuous loading and unloading uses 2 solenoid valves to control the screw compressor slide and
thus its capacity. Control is performed by outlet temperature.
Unit and
compressor
start up and
shutdown
procedure
In the following flow chart the unit startup, management and shutdown procedures are shown, as well
as the compressors loading and unloading strategy.
UNIT ALARM 005
(Evap Flow Alarm)
NO
Unit Startup request
PID requires STANDBY PID requires UNLOAD
Compressor stop required
No new compressor
required
Compressors loading
No compressor stop
required
Compressors
Unloading
Compressor complete unloading
(max 30 s)
Expansion valve closing
Low pressure alarm disabling
Waiting for the evaporating
pressure setpoint to be reached
(with a maximum time)
Line relay opening
PID requires LOAD
A new compressor is required
The compressor with lower
working hours is selected
Opening and closing
electronic expansion valve (pre-purge)
3 s waiting
Line relay closing
Transition confirmation within 10 s
8 s compressor unloading
Compressor enabled to load
Compressors start enabled
PID operation start
Evaporator flow switch consent
within 20 s (manufacturer set)
Start of evap pump 30 s
COMPRESSOR ALARM 008
(Transition fault)
NO
