ESIE07-05 The Digital Controller
Part 2 – Functional Description 2–15
3
2
4
5
1
J7 ID9 digital input Kit heat pump; heating/cooling switch (optional)
ID10 digital input compressor contactors
ID11 digital input auxiliary relay
ID12 digital input motor thermal protection/thermal relay
(optional)
IDC9 powersupply
J10 - LCD connection connection to remote LCD screen
J11 RX/TX- pLAN pLAN
RX/TX+ pLAN pLAN
J12 N01 digital output chiller water pump relay
N02 digital output line contact relay
C1 digital output capacitor
J13 C4 digital output capacitor
N04 digital output condensor pump kit (optional)
N06 digital output loading solenoid valve
J14 C7 digital output capacitor
N07 digital output unloading solenoid valve
J15 C8/N08 digital output 3e step fan/tower
J16 C9 digital output capacitor
N09 digital output liquid injection solenoid valve
N010 digital output antifreeze evaporator heatertape (optional)
N011 digital output remote alarm
J17 C12/N012 digital output 1e step fan/tower
J18 C12/N013 digital output 2e step fan/tower
COMPRESSOR 1
Connector Pin Type Futher information
