Required Tools Si50-402
38 Semi-Hermetic Single Screw Compressor Version IV
8. Required Tools
1. General Tools and Measuring Instruments
Table 8-1 List of general tools and measuring instruments
Table 8-2. List of tightening torque for bolts and nuts (N - m)
Notes: 1. Indicate metric coarse threads and standard bolts (5T, 12.9).
2. Tolerances on tightening torque are ±15%.
However, the tolerance on tightening torque at terminal block is ±5%.
3. When tightening hexagon socket head cap screws in the compressor, apply specifications
for class 12.9.
4. The tightening torque of hexagon socket head screw used for control motor is to be 3.5N-m
±15%.
Name Specification (size) Application
Tools
1 Hex-key wrenches
M5, M6, M8, M10, M12, M16
2 Torque wrench Refer table 8-2
3 POWER BIT VESSEL A16 of 2.5-mm opposite side and 65-mm
total length or equal
(It is better to have an opposite side of shorter
than 2.5 mm in length.)
For installation or disassembly of control
motor
4 Torque wrench
5
C-type retainer ring
removing tools
For holes (large, small) and shafts Gate rotor and bearing holders
6 Guide bolts M6, M8, M10, M12, M16 Fixing plate and cover installation
7 Other general tools
Adjustable end wrench, spanners, pliers,
screwdrivers, hammer, plastic hammer, T-shape
wrenches, chisel
Measuring
instruments
8 Megger taster 500-V megger
9 Depth gauge Dial type (minimum scale division: 0.01 mm) Screw shims (1)
10 Thickness gauges 0.03 to 0.10 mm
Clearance between main bearing holder
and screw and slit clearance
11 Dial gauge Minimum scale division: 0.01 mm, stroke: 10 mm For measuring Backlash
Others
12 Drier Output: Approx. 1000 W For removing moisture from bearing
13 Wire and plug Class 200 V, 40 mA For rotating control motor
14 Grease
Shell Alvania Grease S No. 2 … Inside Japan
Shell Alvania Grease RL No. 2 … Outside Japan
For continuous capacity control unit
Nominal bolt/nut size Terminal nut Locking nut 5T Class 12.9
M5 4.2 — 3.0 11.6
M6 — — 5.2 14.0
M8 — — 12.3 34.0
M10 16.7 25.2 25.2 68.0
M12 26.5 — 42.7 118
M16 — — 103 293
M20 — 26 202 570
M24 — — 348 —
