Required Tools Si50-402
44 Semi-Hermetic Single Screw Compressor Version IV
Jig (2)-2 [Bearing Removing Jig Parts]
(Z0119)
Applicable
model
ZH3_
ZH5F, ZH7_
ZH5G
ZH9_
25
35
25
35
8
12
8
12
9
13
9
13
54
62
46
67
30
40
30
50
Removing bolt
JIS B 1180 fully threaded hexagon head bolt
A M8x70-10.9 chamfered end
JIS B 1180 fully threaded hexagon head bolt
A M12x70-10.9 chamfered end
JIS B 1180 fully threaded hexagon head bolt
A M8x70-10.9 chamfered end
JIS B 1180 fully threaded hexagon head bolt
A M12x70-10.9 chamfered end
2-M6 (through hole)
M (through hole)
