Si50-402 Required Tools
Semi-Hermetic Single Screw Compressor Version IV 39
2. Special Tools
For an overhaul, be sure to prepare jigs listed in Table 8-3.
Table 8-3. List of special tools
Name used in manual Tool name Application Applicable model
Jig(1) Jig(1) Lock nut tightening jig Motor rotor mounting ZH3~9F, G
Jig(2)
Jig(2)-1
Bearing removing jig Removal of suction end cover
ZH3, 5F
Jig(2)-2 ZH3~9F, G
Jig(3) Jig(3)
Temporary bearing holder
mounting plate
Centering of screw ZH3~9F, G
Jig(4)
Jig(4)-1
Handle Adjustment of slit
ZH3, 5F
Jig(4)-2 ZH3~9F, G
Jig(5) Jig(5) Oil filter removing jig Required only for ZH3F ZH3F
Jig(6) Jig(6) Lever Continuous capacity control unit ZH-G
