M
ARGHERITA
Margherita - Instructions for installation and use
Model
ALDS 120
Dimensions
width 59,5 cm
height 85 cm
depth 40 cm
Capacity
from 1 to 4,5 kg
Electrical
connections
voltage 220/230 Volt 50 Hz
maximum absorbed power 1850 W
Water
connections
maximum pressure 1 MPa (10 bar)
minimum pressure 0,05 MPa (0,5 bar)
drum capacity 40 litre
Spinning speed
up to 1200 rpm
Control programs
in compliance
with IEC
regulation 456
programme 3; tempe rature 60°C; rinse level ; wash intensity ;
carried out with 4,5 kg load
This appliance conforms with the following E.E.C. directives:
- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications
- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent modifications
The washing machine
does not drain or spin.
Does the selected
programme incorporates
water draining? Some
programmes stop at the end of
the wash cycles and draining
will have to be selected
manually.
Is the Easy iron" function
-where provided - enabled?
Complete the programme by
pressing the Select button.
Is the drain pump clogged?
To check it, turn off the water
supply, unplug the washing
machine and follow the
instructions on page 25, or call
for technical assistance.
Is the drain hose kinked?
The tract of the drain hose
must be as straight as possible.
Make sure the drain hose is not
squashed or kinked.
Is the washing machines
drain duct clogged? Is there
an extension of the drain
hose? If so, is it positioned
incorrectly, blocking the water
flow?
Excessive vibration
during the spin cycle.
Have all transit screws been
removed durind instal-
lation? See the following
page on installation
procedures.
Has the washing machine
been levelled correctly? The
levelling of the appliance
should be checked
periodically. Adjust the feet
and check them with a level.
Is there space between the
machine and adjacent units?
If it is not a built-in model, the
washing machine will oscillate
a bit during the spin cycle. A
few cm of space should
therefore be left around it.
The washing machine
leaks.
Is the metal ring of the inlet
hose properly attached? Turn
off the water supply, unplug
the appliance and try
tightening its attachment
without forcing it.
Is the detergent dispenser
obstructed? Remove and
wash it under tap water.
Is the drain hose well
attached? Turn off the water
supply, unplug the appliance
and try tightening its
attachment.
Too much foam.
Is the detergent appropriate
for machine washing? Check
whether the definition on its
label reads for machine wash
or hand and machine wash,
or any other similar wording.
Is the correct amount being
used? An excessive amount of
detergent, besides producing
too much foam, does not
guarantee a more effective
wash, and causes scaling in the
internal parts of the appliance.
If, despite all checks, the
washing machine fails to
function and the problem
persists, call your nearest
authorised Customer Service
Centre, providing the following
information:
- the nature of malfunction
- the model type no. (Mod. ....)
- the serial number (S/N ....)
This information can be found on
the data plate situated at the back
of the washing machine.
Technical characteristics
Always get
assistance from
authorised
technicians and
always insist on
original spare
parts.
23
