Gigabyte TRX40 AORUS MASTER (rev. 1.1) [6/104] Box contents

- 6 -

Box Contents

5 TRX40 AORUS MASTER motherboard

5 Motherboard driver disc

5 User's Manual

5 Quick Installation Guide

5 Four SATA cables

5 One Wi-Fi antenna

5 One G Connector

5 One addressable LED strip adapter cable

5 One RGB LED strip extension cable

5 One noise detection cable

5 Two Velcro cable ties

5 Two thermistors cables

5 M.2 screw(s)/M.2 standoff(s)

The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Optional Items

 2-port USB 2.0 bracket (Part No. 12CR1-1UB030-6*R)

 eSATA bracket (Part No. 12CF1-3SATPW-4*R)

 3.5" Front Panel with 2 USB 3.2 Gen 1 ports (Part No. 12CR1-FPX582-2*R)
