7) M2M_32G/M2P_16G(M.2Socket3Connectors)

 TheM.2connectorssupportM.2SATASSDsorM.2PCIeSSDsandsupportRAIDconguration.Please

notethatanM.2PCIeSSDcannotbeusedtocreateaRAIDseteitherwithanM.2SATASSDoraSATA

harddrive.TocreateaRAIDarraywithanM.2PCIeSSD,youmustsetupthecongurationinUEFIBIOS

mode.RefertoChapter3,"ConguringaRAIDSet,"forinstructionsonconguringaRAIDarray.

InstallationNoticesfortheM.2andSATAConnectors:

Due to the limited number of lanes provided by the Chipset, the availability of the SATA connectors may

be affected by the type of device installed in the M2P_16G connector. The M2P_16G connector shares

bandwidthwiththeSATA31connector.Refertothefollowingtablefordetails.

Step 3:

Press the M.2 SSD down and then secure it with the screw.

Select the proper hole for the M.2 SSD to be installed and refasten the screw and nut.
