Gigabyte H370 HD3 (rev. 1.0) [41/48] C 2 uefiraidconfiguration

C-2.UEFIRAIDConguration

Steps:

1. In BIOS Setup, go to BIOS and set CSM Support to Disabled. Save the changes and exit BIOS Setup.

2. After the system reboot, enter BIOS Setup again. Then enter the Peripherals\Intel(R) RapidStorage

Technology sub-menu.

3. On the Intel(R)RapidStorageTechnology menu, press <Enter> on CreateRAIDVolume to enter the

CreateRAIDVolumescreen.Enteravolumenamewith1~16letters(letterscannotbespecialcharacters)

under the Nameitemandpress<Enter>.Then,selectaRAIDlevel.RAIDlevelssupportedincludeRAID

0(Stripe),RAID1(Mirror),RAID10,andRAID5(theselectionsavailabledependonthenumberofthehard

drives being installed). Next, use the down arrow key to move to Select Disks.

4. Under Select Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Pressthe<Space>key

ontheharddrivestobeselected(selectedharddrivesaremarkedwith"X").Thensetthestripeblocksize.

Thestripeblocksizecanbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,setthe

volume capacity.

5. After setting the capacity, move to Create Volume and press <Enter> to begin.

6. After completing, you'll be brought back to the Intel(R)RapidStorageTechnology screen. Under RAID

VolumesyoucanseethenewRAIDvolume.Toseemoredetailedinformation,press<Enter>onthevolume

tocheckforinformationonRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.

PleasevisitGIGABYTE'swebsitefordetailsonconguringaRAIDarray.

C-3.ConguringLegacyRAIDROM

Enter the Intel

legacyRAIDBIOSsetuputilitytocongureaRAIDarray.Skipthisstepandproceedwiththe

installationofWindowsoperatingsystemforanon-RAIDconguration.

Steps:

1. In BIOS Setup, go to BIOS and set CSM Support to Enabled and StorageBootOptionControl to Legacy.

Next, go to Peripherals\SATAAndRSTConguration and make sure UseRSTLegacyOROM is set

to Enabled. Save the changes and exit BIOS Setup. After the POST memory test begins and before the

operatingsystembootbegins,lookforamessagewhichsays"Press<Ctrl-I>toenterCongurationUtility".

Press<Ctrl>+<I>toentertheRAIDCongurationUtility.

2. After you press <Ctrl> + <I>, the MAINMENUscreenwillappear.IfyouwanttocreateaRAIDarray,select

CreateRAIDVolume in MAIN MENU and press <Enter>.

3. After entering the CREATEVOLUMEMENUscreen,enteravolumenamewith1~16letters(letterscannot

be special characters) under the Nameitemandpress<Enter>.Then,selectaRAIDlevel.RAIDlevels

supportedincludeRAID0,RAID1,RAID10,andRAID5(theselectionsavailabledependonthenumberof

the hard drives being installed). Press <Enter> to proceed.

4. Under Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Ifonlytwoharddrivesareinstalled,

theywillbeautomaticallyassignedtothearray.Setthestripeblocksizeifnecessary.Thestripeblocksize

canbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,press<Enter>.

5. Enter the array capacity and press <Enter>. Finally press <Enter> on the Create Volume item to begin

creatingtheRAIDarray.Whenpromptedtoconrmwhethertocreatethisvolume,press<Y>toconrmor

<N> to cancel.

6. Whencompleted,youcanseedetailedinformationabouttheRAIDarrayintheDISK/VOLUMEINFORMATION

section,includingtheRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.ToexittheRAID

BIOS utility, press <Esc> or select 6.Exit in MAINMENU.

3. After completing, you'll be brought back to the Intel(R)RapidStorageTechnology screen. Under RAID

VolumesyoucanseethenewRAIDvolume.Toseemoredetailedinformation,press<Enter>onthevolume

tocheckforinformationonRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.

- 41 -
