Chapter3 Appendix

Beforeyoubegin,pleasepreparethefollowingitems:

• At least two SATA hard drives or SSDs.

(Note 1)

(To ensure optimal performance, it is recommended that you

use two hard drives with identical model and capacity).

(Note 2)

• Windows setup disk.

• Motherboard driver disk.

• A USB thumb drive.

MakesuretoconguretheSATAcontrollermodecorrectlyinsystemBIOSSetup.

Steps:

1. Go to Peripherals\SATAAndRSTConguration, make sure SATAController(s) is enabled. To create

RAID,setSATAModeSelection to IntelRSTPremiumWithIntelOptaneSystemAcceleration. Then

save the settings and restart your computer. Note: When using a PCIe SSD, make sure to set the USERST

LegacyOROM item under Peripherals\SATAAndRSTConguration to Disabled. Then depending the

M.2 connector you use, set the corresponding PCIeStorageDevOnPortXX item to RSTControlled.

2. TousetheEZRAIDfeature,followthestepsin"C-1."TocongureUEFIRAID,followthestepsin"C-2."To

enterthelegacyRAIDROM,referto"C-3"formoreinformation.Finally,savethesettingsandexitBIOSSetup.

3-1 ConguringaRAIDSet

item.SelectthetypeofharddrivesyouuseforRAIDintheType tab and then press <Enter>.

2. Go to the ModetabtoselectaRAIDlevel.RAIDlevelssupportedincludeRAID0,RAID1,RAID10,and

RAID5(theselectionsavailabledependonthenumberoftheharddrivesbeinginstalled).Thenpress

<Enter> to move to the Create tab. Click Proceed to begin.

(Note1) AnM.2PCIeSSDcannotbeusedtosetupaRAIDseteitherwithanM.2SATASSDoraSATAhard

(Note2) Referto"1-7InternalConnectors,"fortheinstallationnoticesfortheM.2andSATAconnectors.

Minimum

Number of Hard
