ELECTRICAL SPECIFICATIONS
33/62
EWAT~B-SS/L
MODEL
EWAT330B-
SS(L)A2
EWAT340B-
SS(L)A1
EWAT350B-
SS(L)A2
EWAT420B-
SS(L)A2
EWAT460B-
SS(L)A2
EWAT510B-
SS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
578
565
575
638
712
717
Nominal running current
cooling
A
207
197
220
238
285
310
Maximum running current
A
265
255
262
332
406
414
Maximum current for wires
sizing
A
291
280
288
365
446
455
FANS
Nominal running current
cooling
A
16
20
16
23
23
26
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
Maximum running current
A
248
235
245
309
383
387
Starting method
DOL
DOL
DOL
DOL
DOL
DOL
MODEL
EWAT570B-
SS(L)A2
EWAT610B-
SS(L)A2
EWAT670B-
SS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
Frequency
Hz
50
50
50
Voltage
V
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
UNIT
Maximum inrush current
A
791
795
800
Nominal running current
cooling
A
358
382
399
Maximum running current
A
487
495
507
Maximum current for wires
sizing
A
536
545
557
FANS
Nominal running current
cooling
A
26
30
36
COMPRESSORS
Phases
No.
3
3
3
Voltage
V
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
Maximum running current
A
461
466
470
Starting method
DOL
DOL
DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: In case of inverter driven units, no inrush current at start up is experienced.
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
The data are referred to the standard unit without options.
For the electrical data of the hydronic kit refer to "Options technical data"
All data are subject to change without notice. Please refer to unit nameplate data.
