59/62
INSTALLATIONS NOTES
TECHNICAL SPECIFICATIONS
General The chiller will be designed and manufactured in accordance with the following European directives:
•
Construction of pressure vessel 2014/68/EU
•
Machinery Directive 2006/42/EC
•
Low Voltage 2014/35/EU
•
Electromagnetic Compatibility 2014/30/EU
•
Electrical & Safety codes EN 60204–1 / EN 60335-2-40
•
Manufacturing Quality Standards UNI – UNI EN ISO 1400
The unit will be tested at full load in the factory (at the nominal working conditions and water temperatures).
The chiller will be delivered to the job site completely assembled and charged with refrigerant and oil.
The installation of the chiller must comply with the manufacturer’s instructions for rigging and handling
equipment.
The unit will be able to start up and operate (as standard) at full load with:
- Outside air temperature from............... °C to............... °C
-
Evaporator leaving fluid temperature between............... °C and............... °C
Refrigerant HFC R-32
Performance Chiller shall supply the following performances:
•
Number of chiller(s):............... unit(s)
•
Cooling capacity for single chiller:............... kW
•
Power input for single chiller in cooling mode:............... kW
•
Heat exchanger entering water temperature in cooling mode:............... °C
•
Heat exchanger leaving water temperature in cooling mode:............... °C
•
Heat exchanger water flow:............... l/s
•
Nominal outside working ambient temperature in cooling mode:............... °C
•
Minimum full load efficiency (EER): …………….. (kW/kW)
•
Minimum part load efficiency (SEER): …………….. (kW/kW)
Operating voltage range should be 400V ±10%, 3ph, 50Hz (or 380V ±10%, 3ph, 60Hz), voltage unbalance
maximum 3%, without neutral conductor and shall only have one power connection point.
Unit description Chiller shall include one or two independent refrigerant circuits, hermetic orbiting scroll
type optimized for R-32 operation, electronic expansion device (EEXV), direct expansion, PHE evaporator,
air-cooled condenser section made with aluminum Microchannel technology, R-32 refrigerant, lubrication
system, motor starting components, control system and all components necessary for a safe and stable unit
operation.
The chiller will be factory assembled on a robust base frame made of galvanized steel, protected by an epoxy
paint.
Sound level and vibrations Sound power level shall not exceed ………dB(A). The sound power levels must be
rated in accordance to ISO 9614 (other types of rating cannot be used). Vibration on the base frame should
not exceed 2 mm/s.
Dimensions Unit dimensions shall not exceed following indications:
- Unit length............... mm
- Unit width............... mm
- Unit height............... mm
Compressors
Hermetic orbiting scroll type optimized for R-32 operation and complete with motor over-temperature and
over-current protection devices. Each compressor equipped with oil heater that keeps the oil from being
diluted by the refrigerant when the chiller is not running. Each compressor is mounted on rubber
antivibration mounts for a quite operation. Unit is delivered with complete oil charge.
Evaporator
The units shall be equipped with a direct expansion plate to plate type evaporator.
•
The evaporator will be made of stainless steel brazed plates and shall be linked with an electrical heater
controlled by a thermostat and shall be insulated with flexible, closed cell polyurethane insulation material.
•
The water connections shall be VICTAULIC type connections as standard to ensure quick mechanical
disconnection between the unit and the hydronic network.
•
The evaporator will be manufactured in accordance to PED approval.
•
Flow switch on evaporator available as option (shipped loose).
•
Water folter on evaporatoravailable as option (shipped loose).
Condenser coil The condenser is made entirely of aluminum with flat tubes containing small channels.
Full - depth louvered aluminum fins are inserted between the tubes maximizing the heat exchange. The
