ELECTRICAL SPECIFICATIONS
36/62
EWAT~B-XS/L
MODEL
EWAT085B-
XS(L)A1
EWAT115B-
XS(L)A1
EWAT180B-
XS(L)A2
EWAT185B-
XS(L)A1
EWAT200B-
XS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
207
319
316
272
482
385
Nominal running current
cooling
A
56
67
78
110
108
122
Maximum running current
A
72
99
98
144
162
170
Maximum current for wires
sizing
A
79
109
108
159
178
187
FANS
Nominal running current
cooling
A
6
8
10
13
10
13
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
Maximum running current
A
66
91
88
131
152
157
Starting method
DOL
DOL
DOL
DOL
DOL
DOL
MODEL
EWAT220B-
XS(L)A2
EWAT230B-
XS(L)A1
EWAT280B-
XS(L)A2
EWAT300B-
XS(L)A1
EWAT310B-
XS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
411
486
407
547
560
573
Nominal running current
cooling
A
135
128
145
158
168
171
Maximum running current
A
196
173
196
237
250
263
Maximum current for wires
sizing
A
215
191
216
261
275
290
FANS
Nominal running current
cooling
A
13
16
16
20
20
20
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
Maximum running current
A
183
157
180
218
230
243
Starting method
DOL
DOL
DOL
DOL
DOL
DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: In case of inverter driven units, no inrush current at start up is experienced.
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
The data are referred to the standard unit without options.
For the electrical data of the hydronic kit refer to "Options technical data"
All data are subject to change without notice. Please refer to unit nameplate data.
