- 15 - Hardware Installation
1-3 System Block Diagram
G481-H80
PCIe3.0 x4
2666/2400/2133 MHz
PCIe3.0 x16
PCIe3.0 x16
8 x SATAIII
DMI3 x4
2666/2400/2133 MHz
2A~2D
PCIe3.0 x16
PCIe x16 slot
(Rear side, support MD2 card)
Skylake-SP
LGA 3647
Socket P0
CPU0
PCIe3.0 x16
PCIe3.0 x8
PCIe x16 slot
(GPU#5)
PCIe x16 slot
(GPU#6)
PCIe x16 slot
(GPU#7)
PCIe x16 slot
(GPU#8)
PLX
PCIe3.0 x16
PLXPLX PLX
Skylake-SP
LGA 3647
Socket P0
CPU1
DDR4
2DPC
6-Channel
DDR4
2DPC
6-Channel
12 x DIMM slots 12 x DIMM slots
2 x10G BASE-T LAN
(Rear Side)
8-bay 2.5” SAS/SATA
Intel
X550-AT2
NVMe
add-on card
PCH
PCIe x16 slot
(GPU#1)
PCIe x16 slot
(GPU#2)
PCIe x16 slot
(GPU#3)
PCIe x16 slot
(GPU#4)
2/3 x UPI @9.6/10.4 GT/s
2-bay 2.5” NVMe
G481-H81
PCIe3.0 x4
2666/2400/2133 MHz
PCIe3.0 x16
PCIe3.0 x16
2666/2400/2133 MHz
2A~2D
PCIe3.0 x16
PCIe x16 slot
(Rear side, support MD2 card)
8 x SATAIII
DMI3 x4
PCIe3.0 x8
8-bay 3.5” SAS/SATA
Optional SAS
add-on card
PCH
4-bay 3.5” SAS/SATA
Skylake-SP
LGA 3647
Socket P0
CPU0
PCIe3.0 x16
PCIe x16 slot
(GPU#5)
PCIe x16 slot
(GPU#6)
PCIe x16 slot
(GPU#7)
PCIe x16 slot
(GPU#8)
PLX
PCIe3.0 x16
PLXPLX PLX
Skylake-SP
LGA 3647
Socket P0
CPU1
DDR4
2DPC
6-Channel
DDR4
2DPC
6-Channel
12 x DIMM slots 12 x DIMM slots
2 x10G BASE-T LAN
(Rear Side)
Intel
X550-AT2
PCIe x16 slot
(GPU#1)
PCIe x16 slot
(GPU#2)
PCIe x16 slot
(GPU#3)
PCIe x16 slot
(GPU#4)
2/3 x UPI @9.6/10.4 GT/s
