- 71 - BIOS Setup
(Note) Functions available on selected models.
Parameter
Description
PCI Bus Driver Version
Displays the PCI Bus Driver version information.
PCI Express Slot #1-1 / #1-2 / #2-1 /
#2-2 / #3-1 / #3-2 / #4-1 / #4-2 / #9 /
#10 / #11 / #12 / #13 / #14 / #15 / #16 /
#17 I/O ROM
(Note)
When enabled, this setting will initialize the device expansion
ROM for the related PCI-E slot.
Options available: Enabled/Disabled. Default setting is Enabled.
Onboard LAN1 / LAN2 Controller
(Note)
Enable/Disable the onboard LAN1 / LAN2 devices.
Options available: Enabled/Disabled. Default setting is Enabled.
Onboard LAN1 / LAN2 I/O ROM
(Note)
Enable/Disable the onboard LAN1 / LAN2 devices, and initializes
device expansion ROM.
Options available: Enabled/Disabled. Default setting is Enabled.
PCI Devices Common Settings
Above 4G Decoding
Enable/Disable memory mapped I/O to 4GB or greater address
space (Above 4G Decoding).
Options available: Enabled/Disabled. Default setting is Disabled.
SR-IOV Support
If the system has SR-IOV capable PCIe devices, this item
Enable/Disable Single Root IO Virtualization Support.
Options available: Enabled/Disabled. Default setting is Enabled.
