Gigabyte H270-F4G (rev. 100) [103/125] 3 10 runtime error logging

- 103 - BIOS Setup

5-3-10 Runtime Error Logging

Runtime Error Logging

System Errors

Enable/Disable system error logging function.

Options available: Enabled/Disabled. Default setting is Enabled.

S/W Error Injection Support

Enable/Disable software injection error logging function.

Options available: Enabled/Disabled. Default setting is Enabled.

Whea Settings

Press [Enter] for conguration of advanced items.

Memory Error Enabling

Press [Enter] for conguration of advanced items.

PCI/PCI Error Enabling

Press [Enter] for conguration of advanced items.
