Gigabyte H270-F4G (rev. 100) [18/125] 2 replacing power supply board cage cover

- 18 - Hardware Installation

2-2 Replacing Power Supply Board Cage Cover

Before you remove or install the power supply board cage cover

• Make sure the system is not turned on or connected to AC power.

Follow these instructions to remove the power supply board cage cover:

1. Loosen and remove the screw securing the cover.

2. Holding the cage and vertically lift it from the system.
