Hardware Installation - 12 -
1-2 Product Specications (Per Node)
Motherboard w H270-F4G: MH70-HD0
w H270-H70: MH70-HD1
CPU w Support for Intel
®
Xeon
®
E5-2600 V3/V4 series processors in the LGA2011
package
w L3 cache varies with CPU
w Supports Dual QuickPath Interconnect up to 9.6GT/s
w Enhanced Intel SpeedStep Technology (EIST)
w Support Intel Virtualization Technology (VT)
Chipset w Intel
®
C612 Express (Wellsburg) Chipset
Memory w 16 x DIMM slots
w DDR4 memory supported only
w Quad channel memory architecture
w ECC RDIMM / LRDIMM modules supported
w Single and dual rank RDIMM modules up to 32GB supported
w 3DS LRDIMM modules up to 128GB supported
w 1.2V modules: 1600/1866/2133/2400 MHz
LAN
(H270-F4G)
w Intel
®
82599ES 10GbE LAN controller with QSFP+
w Realtek RTL8211E supports server management LAN port
LAN
(H270-H70)
w Intel
®
I350 GbE LAN controller
w Realtek RTL8211E supports server management LAN port
Expansion Slot w 1 x PCI Express x16 slot, running at x16 (Gen3)
w 1 x Mezzanine Card, running at x8 (Gen3)
Onboard
Graphics
w ASPEED
®
AST2400 supports 16MB DDR3 VRAM
Mass Storage w 4 x 2.5” Hot-Swap SATA/SAS HDDs
w Support for Intel IRSTe SATA RAID 0, RAID 1, RAID 5, RAID 10
System Fans w 4 x 40x40x56mm 23000rpm
USB w Up to 4 USB 3.0 ports ( 2 on the rear panel I/O, 2 additional ports via the USB
brackets connected to the internal USB headers)
Internal
Connectors
w 2 x 18-pin power connectors
w 1 x Front panel header
w 6 x SATA3 6Gb/s connectors
w 1 x USB 3.0 header
w 1 x TPM module connector
w 1 x SATA SPGIO header
w 1 x BMC SPGIO header
w 1 x PMBUS header
w 1 x IPMB connector
w 1 x Software RAID key connector
w 1 x SATA Power connector (H270-H70 Only)
w 1 x Mananement LAN port cable header (H270-H70 Only)
w 1 x Serial port header
w 1 x VGA port header
